With the Scale command, the selected object is scaled up or down by a specific factor. Enter the scale factor and the base point of the scaling.

Scale tool gif

Example: a sink DXF file is imported, the units were in mm. The sink will be scaled to inches.

  1. From the ‘Change’ tab, select ‘Scale’
    Scale Button
  1. Select the object(s) to be scaled, and confirm with ‘Confirm’ or Enter
  1. Select the scaling point. The objects will be scaled around this point. For sinks, a typical choice would be the front centre point. Click or enter coordinates to set the scaling point.
  1. Now, enter the scaling factor. Then, press enter. To scale from mm to inches, a factor of 0.03937 is used. To scale from inches to mm, a factor of 25.4 is used. Then, press enter.
  1. The selected object(s) are now scaled.
