Start a Series of Measurements – Automatic Measuring

The Start Series of Measurements function on FlexiCAD is a powerful tool that allows you to configure the Flexijet 3D for automated measuring, whereby the Flexijet will automatically produce a series of measurements that are defined by the user. In order to use these functions the Flexijet must be levelled and connected to FlexiCAD.

Flexijet has a number of different ways of setting up automatic measurements to suit your needs, and these are accessed by the drop-down section of the Start Series of Measurements button in the Flexijet ribbon. The user will use these commands to define where Flexijet will measure, at what intervals, the direction, and where to stop measuring.

After defining the series of measurements to me measured, clicking on the Start series of measurements button will initiate the measurement sequence.

*Note: When in automatic measurement mode, Flexijet only captures photo references of the first and last points measured!

Instructions for types of Automatic Measurements:

• Horizontal – Series of Measurements
• Vertical – Series of Measurements
• Parallel to plane – Series of measurements
• Measure along a path – Series of Measurements
• Digitize Hatch
