Copying elements between folders

Elements can be copied between folders in a variety of ways.

Ctrl-c and Ctrl-v (Copy-paste method)

This method can be used to copy and paste elements from one folder to another. Most elements will be pasted on the plane of the destination folder, e.g. vertical elements in a vertical folder can be copied and will be pasted horizontally on a horizontal folder.

1. First, select all the desired elements that you wish to copy. In Touch-mode, use the ‘Select objects’ tool. (see ‘Touch-Mode/PC-Mode’ for more information)
2. Use ‘Ctrl-c’ to copy elements. The command line will read ‘XX elements copied to clipboard’
3. Now, navigate to the destination folder. Use ‘Ctrl-v’ to paste and click/tap the insertion point on the page, or use the command line/coordinates window to specify an insertion point. The objects will be pasted on the active plane of the page.

Copy content from a different folder to active folder

This function will copy elements from a different folder to the active folder, creating a copy of these elements in the current folder.

How to copy elements from a different folder to active folder:

• Right-click on the new folder where elements will copied.
• Activate the command copy elements from a different folder to active folder

• Command window will display the message: Select folder, where elements should be copied from… So, select the folder on the command window by clicking on the name.

• Once you click on the folder, the command window will display the “Copied successfully” message.

Note that this function will leave the copied elements in their original position, which may not be on the current plane. In FlexiCAD/Flexijet Stone version 3.1 and later, the 2D-Projection command can be used to 2d-project elements to the plane of the current folder. Click on the current folder and select Plane>2D projection. All elements in that folder are then projected to the plane of the current folder.
