Printed documents from the ShopFloor client

Various reports can be printed when working off the ShopFloor Operator client.

Also printing can be directed from a specific user terminal to a specific user printer. You can read about how to do this here.

To setup reports to be printed you simply choose an existing NAV report to be printed by assigning the report number in the ShopFloor setup.

ShopFloor setup – assigning reports

Reports available:

A job slip can be printed when a job is started to remind the operator on what he is working on. This is report no 6170471

Request screen:

Job ticket printout sample:

A routing sheet can be printed from the display routing display.

Sample:

A material picking list can be printed from the show BOM screen. Standard NAV material picking list setup.

Material picking list printout sample:

A job card can be printed for each individual routing operations from the Show Route screen. Standard NAV job card list setup.

Job card printout sample:

A pallet label can be printed from the ShopFloor buttons whenever it is wanted. Report no: 6170490

Request button at the operator terminal:

Pallet label printout sample:

A pallet label with lot/serial number can be printed in connection with assigning lot/serial numbers. Report no: 6170492

Pallet label with lot/serial info printout sample:
